10.4 Inch LCD Monitors with 5ms Response Time , 800×600
-
10.4inch real color LCD screen
-
4:3 Aspect Ratio
-
Full metal shielding structure,can profit the external electromagnetic interruption,no radiation.
-
with BNC,VGA, interface
-
Standard VESA install mount.
- Professional appearance design,delicate and generous.
Description:
- Ultra-slim design,convenient use,delicate appearance.
- Industrial A+ grade LCD panel
- High contrast,High brightness,vivid image layout,bets details performance.
- Auto eliminate blur function,long life span.
- Auto adjust VGA image reproduction rate.
- Multiple date-image adjustment circuit,low image distortion.
- Intelligence temperature control fan design,green and quiet.
- Wide visual angle 178°,aspect ratio 4:3
- Rich signal input,output interfaces,adapted in the different environments.
- Appling the latest 3D digital image decode chipset,the latest DNR,image clear,clean and vivid.
- Intensive the IR receiver,support the IR remote to modify the monitor parameters.
- Build-in stable power,low consumption,long life span>60000hours
Applications:
Stock exchanges, Traffic control centers, Airports, media centers, military systems, public space, shopping areas, banks, schools, hospitals, special circumstances etc.
Specifications:
Technical Parameter for LCD Panel
| product | 10.4" HD LCD Monitor |
| model | MJHD-104 |
| Screen type | 10.4" TFT LCD |
| Display area | 214(W)×160(H) |
| Aspect ratio | 4:3 |
| resolution | 800×600 |
| Number of colors | 16.7M |
| Dot pitch | 0.264(H)×0.264(V) |
| brightness | 350cd/㎡ |
| contrast | 450:1 |
| Viewing angle | 140°/150° |
| Response time | 5ms |
| HF | 31k~48kHZ |
| VF | 56~60HZ |
| color system | PAL/NTSC/SECAM |
| Signal interface | Input:2*BNC,1*VGA,1*AUDIO output:1*BNC |
| voltage | DC 12V/2A |
| On mode | ≤18W |
| Standby model | ≤1W |
| Working temperature | 0°~50° |
| humidity | 20%~80% |
| Life | 60000H |
| color | Black/white/customized |
| installment | Desktop/wall mounted |
| certification | CE/3C/FCC/UL |
| Dimension | 238.4×192.4×35 |
| Net weight | 1.8KG |
Competitive Advantage:
Wide voltage range,DC 12V~36V,industrial grade design,can be used in harsh environment.
